Description
Aircraft
Net Weight (with propellers and RTK module) [1]
- 951 g
Max Takeoff Weight
- 1,050 g
Dimensions (Folded/Unfolded)
- Folded (without propellers): 223×96.3×122.2 mm (Length×Width×Height)
- Unfolded (without propellers): 347.5×283×139.6 mm (Length×Width×Height)
Diagonal Length
- Diagonal: 380.1 mm
Max Ascent Speed
- 6 m/s (Normal Mode)
- 8 m/s (Sport Mode)
Max Descent Speed
- 6 m/s (Normal Mode)
- 6 m/s (Sport Mode)
Max Flight Speed (at sea level, no wind)
- 15 m/s (Normal Mode)
- Flying forward: 21 m/s, flying sideways: 20 m/s, flying backwards: 19 m/s (Sport mode) [2]
Max Wind Speed Resistance
- 12 m/s [3]
Max Take-off Altitude Above Sea Level
- 6000 m (without a payload)
Max Flight Time (without wind)
- 43 minutes [4]
Max Hover Time (without wind)
- 37 minutes [4]
Max Flight Distance
- 32 km [6]
Max Pitch Angle
- 30° (Normal Mode)
- 35° (Sport Mode)
Max Angular Velocity
- 200°/s
GNSS
- GPS + Galileo + BeiDou + GLONASS (GLONASS is supported only when RTK module is enabled)
Hovering Accuracy Range
- Vertical: ±0.1 m (Vision Positioning enabled); ±0.5 m (GNSS Positioning enabled); ±0.1 m (D-RTK enabled)
- Horizontal: ±0.3 m (Vision Positioning enabled); ±0.5 m (HD Positioning enabled); ±0.1 m (RTK enabled)
Operating Temperature
- -10° to 40° C (14° to 104° F)
Internal Storage
- N/A
Motor Model Number
- 2008
Propeller Model Number
- 9453F Enterprise Edition
Light Sensor
- Built-in module
